Pen type digital multimeter UA9211D

Pen Type Digital Multimeter with NCV 2000 Counts AC/DC Voltage Pocket multimeter

Auto range pen type digital multimeter with non-contact voltage tester

SPECIFICATIONS:

Environment condition of using:

IEC/EN 61010-1 600V CAT III, Pollution level 2.

Altitude <2000m.

Measuring Principle: Double integral A/D conversion.

Auto range Multimeter.

Measuring rate: (2.5 times - 3 times) / Second Unit showing: showing of function and electrical capacity.

Polarity Indication: '-'indicates negative polarity.

Over range Indication: Display 'OL'.

Data Hold Function: "DATA HM displayed on the LCD.

Power Supply: : 6F22 9V.

Dimension : 225mmx38mmx26mm.

Weight :approx. 333g (including battery.)

Fuse protection - 250mA/250V resettable fuses.

Operation Temperature: : 5~35°C.

Storage Temperature: : -10C~50°C.

--DC Voltage: 200mV/600V

--AC Voltage: 2V/600V

--DC Current: 20mA/200mA

--AC Current: 20mA/200mA

--Resistance: 200 ~ 20 M ohms

--Diode test: Yes

NOTE: Batteries are not included!!!

Specifications
Function	Range	Accuracy
DC voltage	200mV/ 2V/ 20V/ 200V/ 600V	±(0.7%+2)
AC voltage	200mV/ 2V/ 20V/ 200V	±(0.8%+3)
	600V	±(1.0%+3)
DC current	20mA/ 200mA	±(1.5%+3)
AC current	20mA/ 200mA	±(2.0%+3)
Resistance	200Ω/2kΩ/20kΩ/200kΩ/2MΩ	±(1.0%+3)
	20MΩ	±(1.0%+5)
Features
Display	2000 counts
Data hold	YES
MAX. hold	YES
Diode test	YES
Continuity	YES
Non contact Voltage detection	Yes
Mechanical & General Specifications
Power Supply	6F22 9V
Weight	333g
Size	225×38×26mm
Safety Rating	CE CAT. III 600V RoHS
